B-Mass Pellet Press

The external Rolls and Die speed are programmed and automatically adjustable to insure maximum output and minimum energy consumption. The simplified die clamping system allows operator to easily change the die and for the rolls not to be in direct contact with the die surface.

Advantages

The outer roll configuration to the die incorporates the scientific principles of force required to implode a ring structure (which is largely greater than the force required to explode one) resulting in increasing die strength. The pressure detection and rapid roll retraction prevents die cracking and roll and bearing damage originating from foreign objects that may have entered the feedstock. The roll and die design has also eliminated the overheating of roll bearings. Similarly, a variable die speed guarantees thru hardened pellets and vastly improves bulk density.

Die changes have been tested and successfully complete within one hour. The quick release and guided roll assembly also allow the complete roll assembly to be removed in one action and replaced with a prepared assembly. The used roll assembly can then be serviced remotely while the machine is back in operation. The absolute positioning and pressure detection of the rolls also ensures the rolls and die will never come into contact with each other, further preventing unnecessary wear on both elements. Similarly, having a reduced rpm and processed raw material significantly improves key component life.
